pvlib.irradiance.get_total_irradiance#

pvlib.irradiance.get_total_irradiance(surface_tilt, surface_azimuth, solar_zenith, solar_azimuth, dni, ghi, dhi, dni_extra=None, airmass=None, albedo=0.25, surface_type=None, model='isotropic', model_perez='allsitescomposite1990')[source]#

Determine total in-plane irradiance and its beam, sky diffuse and ground reflected components, using the specified sky diffuse irradiance model.

\[I_{tot} = I_{beam} + I_{sky diffuse} + I_{ground}\]

Sky diffuse models include:

isotropic (default)
klucher
haydavies
reindl
king
perez
perez-driesse

Parameters:

surface_tilt (numeric) – Panel tilt from horizontal. See surface_tilt. [°]
surface_azimuth (numeric) – Panel azimuth. See surface_azimuth. [°]
solar_zenith (numeric) – Solar zenith angle. See solar_zenith. [°]
solar_azimuth (numeric) – Solar azimuth angle. See solar_azimuth. [°]
dni (numeric) – Direct normal irradiance. See dni. [Wm⁻²]
ghi (numeric) – Global horizontal irradiance. See ghi. [Wm⁻²]
dhi (numeric) – Diffuse horizontal irradiance. See dhi. [Wm⁻²]
dni_extra (numeric, optional) – Extraterrestrial direct normal irradiance. See dni_extra. [Wm⁻²]
airmass (numeric, optional) – Relative airmass, not adjusted for pressure. See airmass_relative. [unitless]
albedo (numeric, default 0.25) – Ground surface albedo. See albedo. [unitless]
surface_type (str, optional) – Surface type. See get_ground_diffuse() for the list of accepted values.
model (str, default 'isotropic') – Irradiance model. Can be one of 'isotropic', 'klucher', 'haydavies', 'reindl', 'king', 'perez', 'perez-driesse'.
model_perez (str, default 'allsitescomposite1990') – Used only if model='perez'. See perez().

Returns:

total_irrad (OrderedDict or DataFrame) – Contains keys/columns 'poa_global', 'poa_direct', 'poa_diffuse', 'poa_sky_diffuse', 'poa_ground_diffuse'. [Wm⁻²]

Notes

Models 'haydavies', 'reindl', 'perez' and 'perez-driesse' require 'dni_extra'. Values can be calculated using get_extra_radiation().

The 'perez' and 'perez-driesse' models require relative airmass (airmass) as input. If airmass is not provided, it is calculated using the defaults in get_relative_airmass().
